Roland PM-200 Drum Monitor

High Res Personal Drum Monitor

Delivering rich, dynamic sound in a streamlined package, the Roland PM-200 is the ultimate monitoring solution for Roland’s V-Drums. Packing 180 watts of power, the PM-200 features a custom full-range speaker system and rugged cabinet specially optimized for reproducing the famously expressive V-Drums sound and response. And with integrated mixing and direct output capabilities, it’s easy to interface with other devices at home or on stage.

Key Features:

• Premium all-in-one monitor designed for use with V-Drums electronic percussion products
• Equipped with 180 watts of power, a custom 12-inch speaker, and horn tweeter
• Angled design provides ideal sound coverage for the seated player
• Integrated mixer with independent volume controls and global EQ
• Dedicated V-Drums input, plus 1/4-inch and 1/8-inch line inputs for connecting electronic percussion pads, smartphones, and music players
• Two XLR direct outputs, with selectable stereo or dual mono output for a V-Drums module connected in stereo
• Unique full-width bar handle for easy floor adjustment and carrying convenience

Pro-Level Sound for Playing V-Drums

The PM-200 is the perfect complement to any V-Drums set. The custom 12-inch speaker and horn tweeter project big, full-range sound, and 180 watts of power provides ample headroom for both home playing and stage use. The front face is angled for optimal sound monitoring while seated at the V-Drums, and a full-width bar handle on top offers a convenient way to carry the monitor and adjust its floor position.

Versatile Onboard Mixing

With its integrated mixer, the PM-200 allows you to monitor backing music and external devices along with your kit. There’s a dedicated V-Drums input, plus 1/4-inch and 1/8-inch line inputs for connecting electronic percussion pads, smartphones, and music players. Independent volume controls are provided for the V-Drums and line input sections, and a two-band equalizer is on hand for shaping the overall sound.

Direct Outputs for Recording and Stage Performing

The PM-200 is also equipped with two XLR direct outputs to send sounds to a mixer or recording device, providing additional flexibility for using the monitor in stage, rehearsal, and studio applications. And while the PM-200 is a mono monitor, its inputs support stereo connections, enabling you to pass true stereo sound to the direct outputs. When a V-Drums module is connected in stereo to the V-Drums input, a convenient rear panel switch allows you to output its sound in dual mono or stereo to suit the needs of your setup.

Specifications:

• Rated Power Output 180 W
• Nominal Input Level
• V-Drums INPUT: -6 dBu (10 k ohms)
• LINE INPUT: -6 dBu (10 k ohms)
• Speaker 30 cm (12 inches)
• Woofer x 1
• Horn Tweeter x 1
• Controls
• POWER switch
• V-Drums VOLUME knob
• LINE INPUT VOLUME knob
• BASS knob
• TREBLE knob
• Indicators POWER
• Connectors
• V-Drums INPUT jack: Stereo 1/4-inch phone type
• LINE INPUT jack: Stereo 1/4-inch phone type, Stereo miniature phone type
• Direct Out Connector: XLR Type
• AC IN jack
• Power Consumption 64 W

Accessories

• Owner's manual
• Power cord

SIZE AND WEIGHT

• Width 458 mm
• Depth 469 mm
• Height 420 mm
• Weight 21.0 kg
