RCF Evox 5 Compact Portable PA System
Out of stock
Unavailable for purchase
The RCF Evox 5 is a portable small-array PA system that comprises of a column-style satellite speaker and subwoofer. The ultimate all-in-one PA solution for mobile DJs, solo performers and corporate events where power output, acoustic clarity and reliability is essential.
EVOX Makes it Easy
Designed for easy setup and seamless takedown, the EVOX 5 is ideal for bands that tour frequently, or mobile DJs that move between venues. Carrying and mounting a professional audio system has never been so quick!
The Evox 5 system features five 2.0” full range transducers in the line source satellite, and a rugged 10” subwoofer in a bass reflex enclosure.
Although the smallest EVOX model in the lineup, the Evox 5 still features most of the stand-out features that have made this range the trusted, go-to portable PA system. Designed and manufactured in Italy, the EVOX 5 system benefits from strict quality control and transducer production processes that guarantee flawless performance night after night.
RCF Evox 5 Key Features:
- 800 Watt
- 125 dB Max SPL
- 45Hz - 20kHz Frequency Response
- 10” Woofer with 2” V.C.
- 5 x 2” Ultra Compact Full Range Transducers with 1” V.C.
- 120 x 30 Degrees Slightly Tilted Pattern Control
- Innovative DSP Processing
- Pole Mountable
- Easy to Set Up and Transport
Portable PA That Packs A Punch
Equipped with RCF’s Class-D power amplifier technology, the RCF Evox 5 has huge power potential despite being a portable and compact PA system.
With their solid aluminium structure, the amplifier is extremely stable during transport while passive, fan-less heat dissipation is also aided.
Furthermore, the RCF Evox 5 also features an SMPS power supply section to enhance output while maintain low weight.
Incredibly fast attack, realistic transient response and amazing audio while maintaining efficiency and light transport weight are the trademarks of Evox amplifiers.
Superior Sound
With over six decades of design and manufacturing experience, RCF are able to produce highly efficient drivers that perform beyond expectations.
Handling the higher frequencies, the RCF Evox 5 line array features five ultra-compact, full-range 2” drivers that can handle high SPL and power for amazing sonic performance.
Taking care of the low frequencies is a high excursion RCF woofer with its bass-reflex port design minimising air turbulence to reduce unwanted distortion for pristine sound.
Furthermore, you get a constant directivity coverage of 120 degrees x 30 degrees (HxV) for the perfect coverage pattern.
FiR Technology
Making use of proprietary, advanced FiR filtering technology, these speakers produce transparent sound with incredible clarity.
Equipped with special FiRPHASE filters, the Evox 5 is further able to produce consistent and coherent distribution of sound for your entire audience so they can enjoy your music without phase distortion with minimal system latency.
Ready for The Road
As portable as it is great sounding, the RCF Evox 5 is very compact, durable and easy to set up and break down.
Baltic birch plywood construction has been used to ensure a rugged chassis that’s designed for life on the road, offering great durability while maintaining a weight under 20kg.
What’s more; set up and breakdown couldn’t be easier.
When you arrive at the venue, you can easily screw the pole mount into the top of the sub and then place the top column atop the pole.
When you’re finished, the pole mount separates into two parts for increased transport options.
Furthermore, the sub features a specially designed rail where you can store the top speaker column. It slots in with ease so you can easily take the both the sub and top column away as one compact unit.
Portability and Performance
Designed for great portability with performance to match, the RCF Evox 5 is a fantastic portable PA active two-wary array system for smaller venues.
Buy the RCF Evox 5 from PMT Online to get an incredible portable PA system that’s ideal for live music and DJ performance.
RCF Evox 5 Specifications:
Acoustical Specifications
- Freuqncy Response: 45 Hz – 20,000 Hz
- Max SPL @1M: 125 dB
- Horizontal Coverage Angle: 120 Degrees
- Vertical Coverage Angle: 30 Degrees
Transducers
- Fullrange: 5 x 2”, 1” v.c.
- Woofer: 10”, 2” v.c
Input/Output Section
- Input Signal: Bal/Unbal
- Input Connectors: XLR, Jack
- Output Connectors: XLR
- Input Sensitivity: -2 dBu/+4 dBu
Processor Section
- Crossover Frequencies: 220 Hz
- Protections: Thermal, RMS
- Limited: Soft Limiter
- Controls: Volume, EQ, Phase, Xover
Power Section
- Total Power: 800 W Peak, 400 W RMS
- High Frequencies: 200 W Peak, 100 W RMS
- Low Frequencies: 600 W Peak, 300 W RMS
- Cooling: Convection
- Connections: VDE
Physical Specifications
- Cabinet/Case Material: Baltic Birch Plywood
- Hardware: 2 x M6
- Handles: 1 Top
- Pole Mount/Cap: Yes
- Colour: Black
RCF Evox 5 Dimensions:
- Height: 490mm (19.29”)
- Width: 288mm (11.34”)
- Depth: 427mm (16.81”)
- Weight: 18.8kg (41.45lbs)
| Manufacturer | RCF |
|---|---|
| SKU | 128483 |
| Shipping Weight (kg) | 22.000000 |
| MPN | EVOX 5 |
| Warranty | 2 Years |
| Power | 400 Watts (RMS) - 800 watts (Peak) |
| SPL | 125dB |
| Woofer Size | 10" woofer |
